1. Material weight reduction

The Han V2.0 concrete mixer truck adopts vehicle lightweighting technology and the frame is made of high-strength steel; the air cylinder and fuel tank are made of aluminum alloy, which reduces weight while ensuring component performance.

2. Reduce design weight

Through CAN analysis, the frame and suspension system are optimized to ensure load-bearing capacity while reducing weight.

1. Assembly advantages

The Han V2.0 concrete mixer truck uses a special engine for low-idle concrete mixer trucks , which is specially designed for concrete mixer trucks with a lot of waiting conditions. The engine speed is 500 rpm at idle. With the EIAS technology, the torque is increased to 1300N.m, which is the largest torque among engines in the same class.

2. Matched with Shaanxi Gear gearbox , gear shifting is simpler and easier.

3. Match and upgrade the wading bridge to meet the user's wading requirements and prevent water from entering the wheel hub bearing.

1. Knob-type battery frame and new electrical solution improve the reliability of connectors and wiring harnesses.

2. Use Schaeffler imported clutch friction plate to improve vehicle starting smoothness and increase service life by 50%.

1. Upgraded front mirror to improve vision;

2. V-bar low-center-of-gravity suspension increases chassis roll height;

3. Wedge brake to improve braking performance.

1. The small bumper can raise the ground clearance by 155mm and improve the vehicle approach angle by 6°

2. Use a 52mm thick radiator on a mid-axle car carrier, and raise the radiator and water outlet hose to a ground clearance of 62mm

3. Newly designed water tank guard plate and bracket scheme, raising the ground clearance by 95mm and improving vehicle passability
